Model
|
SPS60-SLS
|
SPS80-SLS
|
SPS100-SLS
|
SPS120-SLS
|
SPS150-SLS
|
|
Solar Panel Parameters
|
Mono-crystalline
18V 60W |
Mono-crystalline
18V 80W |
Mono-crystalline
18V 100W
|
Mono-crystalline
36V 120W
|
Mono-crystalline
36V 150W
|
|
Battery Parameters
|
LiFePO4
12.8V 30AH
|
LiFePO4
12.8V 36AH
|
LiFePO4
12.8V 42AH
|
LiFePO4
25.6V 24AH
|
LiFePO4
25.6V 30AH
|
|
System Voltage
|
12V
|
24V
|
|||
|
Light Distribution
|
Type I /Ⅱ/ III / IV / V
|
||||
|
LED Brand
|
3030
|
||||
|
CCT
|
2700K~6500K, RA>70
|
||||
|
Charge Time
|
6~8 Hours
|
||||
|
Working Time
|
No limitation on rainy days
|
||||
|
Protection Grade
|
IP65/IK08
|
||||
|
Luminous Efficiency
|
170Lm/W
|
||||
|
Mounting Caliber
|
70-76mm（suggestion）
|
||||
|
Body Sensor
|
160°，>9m , Activated by customer’s need
|
||||
|
Battery Power Indicators
|
100%-75%-50%-25%-15%
|
||||
|
100%-75%-50%-25%
|
RED/BLUE/GREEN
|
||||
|
Operating Temperature
|
-20℃ to 60℃
|
||||
|
Warranty
|
3 Years for battery / 5 years for led lamp/ 10years for solar panel
|
||||
|
Material
|
Aluminum
|
||||
|
Luminous Flux
|
8500lm
|
10200lm
|
13600m
|
17000lm
|
25500
|
|
LED Lamp
Nominal Power
|
50W
|
60W
|
80W
|
100W
|
150W
|
|
Net Weight
|
18.2kg
|
19kg
|
19.9kg
|
20.8kg
|
22.8kg
|
|
Mounting Height
|
6-7m
|
6-8m
|
6-8m
|
8-9m
|
9-11m
|
|
Space between
2 lamps
|
20-25m
|
20-25m
|
20-25m
|
25-30m
|
30-35m
|
